VESSEL IDENTIFIER: ZAD10
Price: U.S. $ 450,000.00 PRICE REDUCED TO US$175,000.00
DIMENSIONS |
||
| Feet | Meters | |
| Length | 135 | 41.2 |
| Width | 38 | 11.6 |
| Depth | 19' 11" | 3.6 |
| Draft | 18'7" | 5.4 |
| Air Draft (light) | 65 | 19.8 |
| Eye Sight | 30 | 9.1 |
| Speed | Knots | |
| Consumption | 9 Tons/Day | |
| PARTICULARS | |
| Flag | US |
| Year Built | 1974 |
| Last Dry-docked | 2012 |
| Loadline | Expired Aug 30, 2017 |
| Location | Washington State |
|
GRT |
199 |
| Accommodations | 9 |
MORE INFORMATION AND PICTURES BELOW
| Power | |
Main Engines |
2 - EMD L16-645 E5 5,759 Total |
Reduction Gear |
Lufkin 3622 |
|
Generator |
2 - GM B-71 - 99 KW |
| Propeller | 2 - 4 Blade 122.5"x121/8" in Kort Nozzles |
| Other | "Orville Hook" barge retrieval system |
| Winch | Double Drim Intercon DD 225 & GM 6-71 |
| Bollard Pull | 87.5 Tons |
| Fuel Capacity | 172,000 Gallons |
